Copper Wire Twisting Machine High Speed Double Twist Design FC-800B Bunching Equipment

Gambar besar : Copper Wire Twisting Machine High Speed Double Twist Design FC-800B Bunching Equipment

Detail produk:

Tempat asal:	JIANGSU, Tiongkok
Nama merek:	Fuchuan
Sertifikasi:	CE
Nomor model:	FC-800B-2T

Syarat-syarat pembayaran & pengiriman:

Kuantitas min Order:	1 set
Harga:	USD 33000-41000 / Set
Kemasan rincian:	Kotak kayu kelas ekspor dengan kemasan tahan guncangan
Waktu pengiriman:	15-45 hari kerja setelah setoran
Syarat-syarat pembayaran:	T/T, L/C, Western Union
Menyediakan kemampuan:	20 set per bulan

Kontak

Copper Wire Twisting Machine High Speed Double Twist Design FC-800B Bunching Equipment

Deskripsi

model:	FC-800B-2T	Diameter kawat tunggal:	0,20-1,20mm
Area bagian yang terdampar:	2,5-16,0 mm2	Kisaran nada:	30-180 mm (12 zona)
Kecepatan Putar Maks:	1500 rpm (3000 putaran/menit)	Tenaga Motorik Utama:	11kW
Kontrol Ketegangan:	Layar sentuh + PLC + kopling bubuk magnetik	Modus rem:	Rem Elektromagnetik
Metode lintas:	Unit penggerak cincin bergulir, pitch belitan yang dapat disesuaikan	Modus Operasi:	Layar Sentuh
Kumparan angkat:	Diameter luar 800 mm	Dimensi:	3600L x 2000W x 1900H mm
Menyoroti:	Copper wire twisting machine , High speed double twist bunching , FC-800B wire bunching equipment

Copper Wire Twisting Machine High Speed Double Twist Design FC-800B Bunching Equipment High-speed double twist design for double output per spindle rotation Copper wire twisting machine FC-800B with high-speed double twist design, rolling ring traverse, 11KW, CE certified. Key Features High-speed double twist design for copper twisting and bunching Rolling ring traverse for evenly wound bobbins Adjustable pitch and breadth for flexible production Constant tension from empty
