0.05-2.52mm tembaga paduan kawat penggilingan kaleng memutar bundching mesin

Gambar besar : 0.05-2.52mm tembaga paduan kawat penggilingan kaleng memutar bundching mesin

Detail produk:

Place of Origin:	CHINA
Nama merek:	FUCHUAN
Sertifikasi:	ISO9001 2008
Model Number:	FC-T32-2

Syarat-syarat pembayaran & pengiriman:

Minimum Order Quantity:	1SET
Harga:	USD30000
Packaging Details:	simply water proof packing
Delivery Time:	8weeks
Payment Terms:	T/T, L/C
Supply Ability:	500sets one year

Kontak

0.05-2.52mm tembaga paduan kawat penggilingan kaleng memutar bundching mesin

Deskripsi

jumlah kabel masuk:	32PCS	Warna Mesin:	biru langit atau hijau apel
cocok untuk kawat:	0,08-0,25mm/0,15-0,64mm	Bayar gelendong:	Dia 300mm
metode penggilingan:	Penggilingan tabung	Kecepatan maksimum:	300M/Min
metode pembayaran:	sikat pembayaran
Menyoroti:	copper wire annealing machine , cable coiling machine

Fuchuan 32 Pcs Round Copper Wire Annealing Machine With Hot Dip Tinned Mehod

Characteristics:

Good annealing heat preservation, save electricity, achieve industry-leading level, Easy to operate,

Specification:

Equipment models	FC-T32-2
Twisting usage	It is mainly applied to the annealing of ultra-fine round copper wire and alloy wire.
Single wire dia(mm)	φ0.08-φ0.25 or φ0.15-φ0.64mm
Max numbers of inlet wire	32pcs
Linear speed	Max:300m/min
Pay off method	Brush pay off
Pay off bobbin model	φ300bobbin
Annealing furnace length	3.5m or 6m
Annealing method	Tube annealing
Annealing protection method	Water seal protection
Tinned method	Hot dip
Capstan control method	Inverter+ motor control or adopt stepless speed regulation motor
Equipment total power	68kw
Take up control	Take up is voltage regulator control the moment motor
Take up bobbin size	5inch,8inch bobbin or 5inch,8inch,10inch bobbin
Traverse control method	Stepless speed regulation motor+ turbine gear box control toothrow traverse
Installation size	24000L2200W2100H

Other Information

FOB SHANGHAI

Payment

TT, L/C

Delivery

FOB Shanghai/Ningbo

Origin

China

Minimum Order

1 set

Package

with container

0.05-2.52mm tembaga paduan kawat penggilingan kaleng memutar bundching mesin 0

0.05-2.52mm tembaga paduan kawat penggilingan kaleng memutar bundching mesin 1

0.05-2.52mm tembaga paduan kawat penggilingan kaleng memutar bundching mesin 2
